E93 Brief Description

E93 Brief Description

E93 is a high-density special copper bearing alloy as a matrix material CuSn rolled into having a carrying capacity, good wear resistance characteristics. Based on the good performance of copper easy processing and advanced tooling, E93 bearing surface of the strip can be processed to adapt to a variety of working conditions of oil pockets (standard products for the diamond oil hole), tank, so that the bearing can be stored in use a lot of grease, oil film at the beginning of work, to reduce the coefficient of friction, the work to extend the refueling interval period, effectively improve the bearing life. Compared with the traditional copper sleeve.

E93 Chemical Composition

Part No Material Cu Sn P Pb Zn
E93 CuSn8 91.3% 8.5% 0.2% / /

Composition of E93 and standard oil hole

E93 Oil Indentations/Holes

E93 Material Characteristics

Max. Load Capacity
Static Load N/mm2 120
Dynamic load N/mm2 40
Max. Speed
E93 m/s >2.5
Max. PV Value N/mm2 · m/s 2.8
Tensile Strength N/mm2 · m/s 450
Yiled Point N/mm2 · m/s 250
Hardness HB 90-120
Elongation   40%
Coefficient of Friction μ 0.08~0.25
Operation Temperature Range -100~200
Thermal Conductivity W/(m · k) 60
Coefficient of Thermal Expansion k-1 15×10-6
